0.96 inch Arduino SPI TFT Display
Arduino SPI TFT ScreenIt has a screen size of 0.96 inches. Screen mode is black IPS. The connection information of the 8-pin product is as follows:
1-GND: Power Ground
2-VCC: Power +3.3
3-SCL: Serial clock pin
4-SDA: Serial data input
5-RES LCM reset pin
This pin resets the signal input. When the pin is low the chip gets harder to start. Keep this pin high during normal operation.
6-DC: Data / command selection foot
7-CS: Chip selection
8-BLK: Backlight control pin
0.96 inch Arduino SPI TFT Display Technical Specifications
- Size: 0.96 inch
- Display mode: Normally black IPS
- Display format: Graphic 80RGB * 160 Dot-matrix
- Input data SPI interface
- Driver IC ST7735S
- Dimensional outline: 24 (W) * 30 (H) * 2.8 +/- 0.1 (T) mm
- Resolution: 80RGB * 160 dots
- LCD active area 10.8 (W) * 21.7 (H)
- Dot pitch 0.135 (H) x 0.1356 (V) mm
- Viewing direction: Whole view
- Working temperature: -20 ~ 70 ° c
