Huskylens - Easy to Use Artificial Intelligence Machine Vision Sensor
HuskyLens,is an easy to use artificial intelligence machine vision sensor. It is equipped with multiple functions such as face recognition, object tracking, object recognition, line tracking, color recognition and tag (QR code) recognition.
Through its UART / I2C port, HuskyLens can connect popular mainstream control boards such as Arduino, micro: bit, Raspberry Pi, and LattePanda to help you do very creative projects without playing around with complex algorithms.
HuskyLens is very easy to use. You can change various algorithms by pressing the function button. Click on the Learning button and HuskyLens starts learning new things. After that, HuskyLens can recognize them.
HuskyLens also carries a 2.0 inch IPS screen. Therefore, you do not need to use a PC for parameter setting.
HuskyLens are designed to be smart. It has built-in machine learning technology that enables HuskyLens to recognize faces and objects. What's more, with a long press on the learning button HuskyLens can constantly learn new things, even from different angles and at various intervals. The more he learns, the more accurate he will be.
HuskyLens adopts a new generation of custom AI chip Kendryte K210. The performance of this particular AI chip is 1,000 times faster than that of the STM32H743 when running the neural network algorithm. With these excellent performances, it can even capture fast moving objects.
With HuskyLens, your projects have new ways to interact with you or your environment, such as interactive motion control, autonomous robot, smart access control, and interactive toy.
Gravity: Huskylens Artificial Intelligence Machine Vision Sensor Specifications
Manufacturer | DFRobot |
Product Category | Vision Sensor |
Processor | Kendryte K210 |
Image Sensor | OV2640 (2.0Megapixel Camera) |
Supply Voltage | 3.3V ~ 5.0V |
Current Consumption (TYP) | 320mA@3.3V, 230mA@5.0V (face recognition mode; 80% backlight brightness; fill light off) |
Connection Interface | UART, I2C |
Screen | 2.0 inch IPS screen with 320 x 240 resolution |
Built-in Algorithms | Face Recognition, Object Tracking, Object Recognition, Line Tracking, Color Recognition, Tag Recognition |
Size | 52mm x 44.5mm / 2.05 x 1.75 inch |
Package Included:
1 x HuskyLens Motherboard
6 x M3 Screws
6 x M3 Nuts
1 x Small Mounting Bracket
1 x Upgrade Bracket
1 x Gravity 4-Pin Sensor Cable
Documents
- WikiCheck out the page.
- Trainings for Devastator Tank, Romeo and HUSKYLENSCheck out the page.
- Mind + (Scratch3.0 Based Offline Editor)download for free.
