ADXL335 - 5V Compatible Three Axis Accelerometer
AdafruitOne of the most popular three-axis accelerometers, this board has a 3.3V regulator. This makes it a great option for 5V-powered environments such as Arduino. The module has 3 analog outputs that reflect measurements to the X, Y and Z axes. All of this is packed into a few 1.9cm x 1.9cm behind. On the cardADXL335integratedAnalog DevicesIt is one of the latest and most perfect integrations produced by. This firm is of premium qualityMEMSIt is famous for its devices. The VCC regulates and converts input up to 5V to 3.3V and transmits it to an output pin. Analog outputs are proportional, so 0g measurement is always half of 3.3V (1.65V), -3g is 0V and + 3g is 3.3V. The values in between are proportional.
Adafruit ADXL335 - 5V Compatible Triaxial Accelerometer Features
- Dimensions W x L x H: 19mm x 19mm x 3.14mm
- Weight excluding pins: 1.27g
- Working input voltage: 5V - 5.5V
- Measuring range min: + -3G
- Measuring range typical: + -3.6G
- Measurement error linier error: + - 0.30%
- Between Streams Error: + - 1%
- Sensitivity ratiometric (3V) min: 270mV / G
- Sensitivity ratiometric (3V) typical: 300mV / G
- Sensitivity ratiometric (3V) max: 330mV / G
- Zero G output voltage (3V) min: 1.35V (Z = 1.2V)
- Zero G output voltage (3V) typical: 1.5V
- Zero G output voltage (3V) max: 1.65V (Z = 1.8V)
- Working current typical: 0.5mA
- First reaction time: 1mSec
- Usage areas:
- * Acceleration measurement, Speed measurement, Tilt measurement
