ESP 32 LoRa Development Board Wifi Kit - With 0.96 Inch OLED Display
ESP32 LoRa Development Board Wifi Kitseries, low cost network utility, ESP32, using LX6 dual-core processor, the main chip has been redeveloped, 240MHz, 600DMIPS, built-in chip 520 KB SRAM, provides computing power up to 802.11 b / g. The N HT40 Wi-Fi transceiver, baseband, protocol stack and LWIP have integrated dual-mode Bluetooth. (traditional Bluetooth and BLE low power Bluetooth).
This product is added to WIFI Kit 32, added SX1278 chip, that is, LoRa ™ remote modem, 868MHz frequency, about -148dBm high sensitivity, +20 dBm power output, high reliability, transmission distance (measured open area communication distance 2.6Km)
Built-in 32MByte Flash, Wi-Fi antenna, 0.96 inch blue OLED screen, lithium battery charging circuit and interface, CP2102 USB for serial chip, perfect support for Arduino development environment, can be very simple and fast for program validation and product development.
ESP 32 LoRa Development Board Technical Specifications
- Frequency: 868MHz
- Working voltage: 3.3V to 7V.
- Operating temperature range: -40 ° C to + 90 ° C
- Supports Sniffer, Station, softAP and Wi-Fi Direct modes.
- Transmission power: 19.5 dBm @ 11b, 16.5 dBm @ 11g, 15.5 dBm @ 11n.
- Data rate: 150 Mbps @ 11n HT40.72 Mbps @ 11n HT20.54 Mbps @ 11g, 11 Mbps @ 11b.
- Up to the receiver - 98 dBm sensitivity.
- UDP continues to produce 135 Mbps.
